Trailer Tire Load Range Chart: C, D, E, F Compared (2026)

If you've ever stood in a tire shop looking at trailer tires and seen letters like "Load Range C" or "Load Range E" stamped on the sidewall, you're not alone. This is one of the most confusing aspects of trailer tire shopping — and getting it wrong can lead to premature wear, poor handling, or worse, a tire failure on the highway.

This guide breaks down exactly what load range means, how each range compares, and how to determine which load range your trailer needs.

What Is Load Range?

Load range is a standardized rating that indicates a tire's load-carrying capacity and its maximum inflation pressure. It's not a measure of the tire's physical size — two tires with the same dimensions (like ST225/80R15) can have different load ranges and completely different capabilities.

Think of load range as a tire's "strength rating." A higher load range means:

• Higher load capacity — the tire can carry more weight
• Higher maximum inflation pressure — the tire is designed to operate at higher PSI
• Stronger construction — more and/or thicker ply layers in the tire body

The Ply Rating System

Load range is directly tied to the tire's ply rating — the number of layers (plies) in the tire's casing. More plies = stronger tire = higher load range.

| Load Range | Ply Rating | Construction | Typical Max Pressure |

|------------|-----------|-------------|---------------------|

| Load Range B | 4-ply | Standard bias or light radial | 35–50 PSI |

| Load Range C | 6-ply | Enhanced bias or light radial | 50–60 PSI |

| Load Range D | 8-ply | Heavy-duty bias or radial | 65–80 PSI |

| Load Range E | 10-ply | Extra-heavy bias or radial | 80–100 PSI |

| Load Range F | 12-ply | Maximum heavy-duty bias or radial | 95–110 PSI |

Important: The "ply rating" no longer necessarily reflects the actual number of physical plies. Modern tire construction uses stronger materials (steel belts, synthetic cords) that allow fewer physical plies to achieve the same load capacity. But the load range numbering system remains the same for consistency.

Load Range C: The Light-Duty Standard

Load Range C tires are the most common choice for light trailers — boat trailers, small utility trailers, and single-axle campers under 3,500 lbs per axle.

Load Range C Specifications

• Ply rating: 6-ply
• Typical max pressure: 50–60 PSI
• Max load per tire (205/75R14): ~1,820 lbs at 60 PSI
• Best for: Boat trailers, jet ski trailers, small utility trailers, bike trailers

Pros

• Lower inflation pressure means a slightly softer ride
• Lighter weight
• Lower cost than higher load ranges
• Widely available

Cons

• Lower load capacity — not suitable for heavy trailers
• More susceptible to damage from under-inflation
• Shorter lifespan when overloaded

When to Choose Load Range C

Choose Load Range C when your trailer's gross weight (trailer plus cargo) stays well below the tire's rated capacity. This is common for:

• Boat trailers carrying boats under 16 feet
• Small utility trailers under 2,000 lbs GVWR
• Single-axle trailers with light cargo

Warning: Many boat trailer owners use Load Range C tires even when their boat plus trailer approaches 3,500 lbs. This is risky — if you're near the tire's capacity limit, upgrade to Load Range D for a safety margin.

Load Range D: The Medium-Duty Workhorse

Load Range D tires are the go-to choice for medium-duty trailers — travel trailers, horse trailers, enclosed cargo trailers, and dual-axle setups in the 3,500–7,000 lbs range.

Load Range D Specifications

• Ply rating: 8-ply
• Typical max pressure: 65–80 PSI
• Max load per tire (225/75R15): ~2,150 lbs at 80 PSI
• Best for: Travel trailers, horse trailers, enclosed cargo trailers, medium utility trailers

Pros

• Significant load capacity increase over Load Range C
• Better resistance to damage from road debris
• More forgiving of slight under-inflation
• Good balance of performance and cost

Cons

• Requires higher inflation pressure (not all owners adjust for this)
• Slightly firmer ride than Load Range C
• Higher cost than Load Range C

When to Choose Load Range D

Choose Load Range D when:

• Your trailer's GVWR exceeds 3,500 lbs
• You tow frequently on highways at 65+ mph
• You carry heavy cargo (equipment, supplies, live animals)
• You want a safety margin above your trailer's rated capacity

This is the most common load range for consumer trailer applications. If you're towing a travel trailer, horse trailer, or enclosed cargo trailer, Load Range D is likely what you need.

Load Range E: The Heavy-Duty Standard

Load Range E tires are designed for heavy trailers — large travel trailers, gooseneck trailers, equipment trailers, and commercial applications in the 5,000–12,000 lbs range.

Load Range E Specifications

• Ply rating: 10-ply
• Typical max pressure: 80–100 PSI
• Max load per tire (235/80R16): ~3,040 lbs at 95 PSI
• Best for: Large travel trailers, gooseneck trailers, equipment trailers, commercial trailers

Pros

• High load capacity for heavy trailers
• Excellent resistance to heat buildup at highway speeds
• Strong sidewalls resist damage from curbs and debris
• Longer lifespan under heavy loads

Cons

• Requires high inflation pressure (80–100 PSI) — not suitable for low-pressure applications
• Firmer ride quality
• Heavier weight
• Higher cost
• Not available in all tire sizes

When to Choose Load Range E

Choose Load Range E when:

• Your trailer's GVWR exceeds 7,000 lbs
• You tow large travel trailers or fifth wheels
• You carry heavy equipment or machinery
• You tow in hot climates where heat buildup is a concern
• Your trailer manufacturer specifies Load Range E

Most dual-axle travel trailers and gooseneck trailers require Load Range E tires. Always check your trailer's placard or owner's manual for the manufacturer's specification.

Load Range F: The Maximum Duty Option

Load Range F tires are the heaviest-duty option available for trailer applications. They're used in commercial and industrial applications where maximum load capacity is critical.

Load Range F Specifications

• Ply rating: 12-ply
• Typical max pressure: 95–110 PSI
• Max load per tire (315/80R22.5): ~6,610 lbs at 110 PSI
• Best for: Heavy commercial trailers, dump trailers, lowboy trailers, industrial applications

Pros

• Maximum load capacity
• Exceptional heat resistance
• Longest lifespan under heavy loads
• Best option for extreme duty cycles

Cons

• Very high inflation pressure requirements
• Very firm ride
• Very heavy
• Very expensive
• Limited size availability
• Overkill for most consumer applications

When to Choose Load Range F

Load Range F is typically reserved for:

• Commercial dump trailers
• Heavy equipment transport
• Industrial and construction applications
• Applications where the trailer is near or at maximum legal weight

For most consumer trailer owners, Load Range E is the heaviest duty option you'll need.

Bias vs. Radial: How Construction Affects Load Range

Trailer tires come in two construction types — bias and radial — and the load range behaves differently depending on construction.

Bias Ply Tires

Bias ply tires have layers of fabric (plies) arranged at alternating angles (typically 30–40 degrees). This creates a stiff, durable tire that's traditionally been the standard for trailer use.

• Pros: Stiff sidewalls resist sway, generally less expensive, widely available
• Cons: Runs hotter than radials, shorter tread life, less comfortable ride, more susceptible to heat buildup at highway speeds

Radial Tires

Radial tires have plies arranged at 90 degrees to the direction of travel, with steel belts underneath the tread. This creates a more flexible tire that flexes with the road surface.

• Pros: Cooler running, longer tread life, better handling, more comfortable ride, better fuel efficiency (less rolling resistance)
• Cons: Softer sidewalls can increase sway in some applications, generally more expensive

Important: Radial and bias tires should never be mixed on the same trailer. The different handling characteristics can create instability.

Load Range and Construction Interaction

A Load Range E radial tire and a Load Range E bias tire have the same load capacity and maximum pressure, but they perform differently:

• The radial runs cooler and lasts longer
• The bias has stiffer sidewalls (which can help or hurt depending on your trailer)
• The radial provides a smoother ride
• The bias is typically less expensive

For most modern trailer applications, radial tires are preferred — especially for highway towing. The cooler running and longer lifespan usually justify the higher cost.

How to Determine Your Trailer's Required Load Range

This is the question that matters most. Here's how to figure it out:

Method 1: Check Your Trailer's Placard

Most trailers have a weight and tire information placard mounted inside the trailer (on a wall, near the door, or on the frame). This placard specifies:

• GVWR (Gross Vehicle Weight Rating)
• Required tire size
• Required load range
• Required inflation pressure

This is the most authoritative source. If your trailer has a placard, follow its specifications.

Method 2: Calculate from Your Trailer's Weight

If your trailer doesn't have a placard (or it's faded/unreadable), calculate the required load range:

1. Find your trailer's GVWR — check the title, registration, or manufacturer's documentation
2. Divide by the number of tires — this gives you the maximum load per tire
3. Add a 15–20% safety margin — you don't want to be running at the tire's absolute limit
4. Look up the load capacity in a tire load/inflation chart for your tire size

Example: A 7,000 lb travel trailer with 4 tires:

• 7,000 ÷ 4 = 1,750 lbs per tire
• Add 20% margin: 1,750 × 1.2 = 2,100 lbs required per tire
• A 225/75R15 Load Range D tire carries 2,150 lbs at 80 PSI — this meets your requirement
• A 225/75R15 Load Range C tire carries 1,820 lbs at 60 PSI — this is borderline and not recommended

Method 3: Consult Your Trailer Manufacturer

If you can't determine the load range from the placard or calculations, contact your trailer manufacturer with your trailer's VIN. They can tell you exactly what tire specification was required.

Method 4: Use a Tire Load/Inflation Chart

Tire manufacturers publish load/inflation charts that show the maximum load each tire size can carry at each inflation pressure, broken down by load range. Here's a simplified chart for common trailer tire sizes:

ST205/75R14 (14-inch trailer tire):

| Load Range | 50 PSI | 60 PSI |

|-----------|--------|--------|
